CYC175Q – Cyclorama Fixture with 175W RGBW LEDs

CYC175Q – Cyclorama Fixture with 175W RGBW LED Technology

The CYC175Q is a professional cyclorama lighting fixture designed to provide smooth and uniform wall washing, backdrop illumination, and stage lighting effects. Powered by a high-output 175W RGBW LED engine, it delivers vibrant colors, excellent color mixing, and reliable performance for theatres, studios, event venues, houses of worship, and architectural lighting applications.

Featuring advanced RGBW color mixing technology, the fixture offers rich color saturation and smooth transitions for dynamic lighting designs. Its flicker-free operation and selectable PWM frequency make it suitable for broadcast, television, and video production environments where consistent image quality is essential.

Photometric Specifications

• Light Source: 175W LED Engine
• Color Mixing: RGBW Color Mixing System
• PWM Frequency: Adjustable from 1.2kHz to 20kHz
• Flicker-Free Operation: Yes
• LED Lifespan: Up to 50,000 hours

Features & Effects

• Dimming: Smooth 0%–100% intensity control
• Strobe Effect: Variable-speed strobe function
• Color Performance: Rich RGBW color blending for cyclorama and wall wash applications

Electrical Specifications

• Input Voltage: 100–240V AC, 50/60Hz
• Power Consumption: 175W
• Power Connection: Powercon input and output

Control & Connectivity

• Operating Modes: DMX and RDM
• DMX Channel Modes: 2CH, 4CH, 6CH, and 8CH
• Control Interface: 5-pin XLR DMX connection
• Display: LCD display with 4-button control panel

Construction & Design

• Housing Material: Durable aluminum construction
• Finish: Professional matte black coating
• Dimensions: 193 × 190 × 267 mm
• Weight: 2.7 kg

Applications

The CYC175Q is ideal for stage backdrops, cyclorama lighting, theatre productions, event venues, television studios, exhibition spaces, and architectural wall-washing applications requiring consistent and vibrant illumination.
